DZO PICTOR 12-25/20-55/50-125MM T2.8 BLACK BUNDLE

DZOfilm Pictor Kit 12-25mm T2.8 / 20-55mm T2.8 / 50-125mm T2.8 Black PL / EF Mount

• Lenses maintains focus throughout the zoom range
• T2.8 to T22 aperture range
• Swappable PL mount. Canon EF included
• 95mm front diameter and 86mm filter thread
• 16-Blade Iris for creamy smooth bokeh
• Parfocal design and near-zero breathing
• 0.8 MOD Cine-Style F/I/Z Gears

Bundle consisting of DZOFilm Pictor Zoom 12-25mm T2.8, 20-55mm T2.8 and 50-125mm T2.8 super 35 lenses. Covers any focal length you may need, in a compact uniform design and consistent ergonomics of standard M0.8 gear rings.

Correlated And Sense Of Space

Deeper DOF and wider FOV captures broaderwider background. Rendering the atmosphere, clearly showings the relationship among subjects, characters and surroundings. Expanding distance between objects and background, reflects the artistic sense of space.

Capturing

The distortion of wide angle lens, exaggerates emotion of characters and highlights the dramatic expression.

Visual Effect

Capturing exaggerating movement, aggrandizes the rhythm of image and enhances the
visual impact in the story.

Professional Cine Lenses With Concrete Build

DZOFILM is devoted to exploring the aesthetic of film and design of optics. Both mechanics and optics are
designed to be compact and versatile, allowing users to enjoy the smooth and precise operation and
every shooting moment with Pictor Zoom.

Parfocal Design - Center image stay sharp during zooming in or out

No matter from close-up to wide shot, or rapidly zoom out to long shot, under Parfocal design, focus keeps still all the way along.

Minimal Breathing

Thanks to the floating structure, the breathing of Pictor Zoom lenses are negligible during focusing.

Versatile In Ultra Compact

At just 1.6kg – 1.8kg Pictor zoom can be easily mounted on a crane, jib, tripod, ROV and other moving platforms, and provides safer and more efficient work methods by reducing heavy lifting. Be a better run-and-gun filmmaker with no fear of complicated scenes or quick shooting, save time by not changing lenses frequently, use Pictor zoom, and never miss an inspiring moment.

Gentle Sharpness & Vivid Look

From feature film, commercial, to documentary, Pictor Zoom captures crisp details while expressing organic look and cinematic texture.

Dreamatic Bokeh & Esthetic Transition

During the focus fall-off, 16 blades T2.8 iris generated soft bokeh. The natural transition from focus to de-focus conveys the ambiance and highlights the subject.

Speed Up Your Shooting - Consistent Design & Higher Efficiency

Highly consistent in color and mechanical control, satisfying most shooting demands. Efficient management with the consistent ergonomics of standard M0.8 gear rings. Multiple ways of mounting follow focus, speed up your shooting.

12-25mm:

• T-Stop: T2.8 – T22
• Optical Construction: 21 elements in 15 groups
• Close Focus: 0,4m
• Iris Control: 64.4°
• Focus Control: 270°
• Zoom Control: 100°
• Iris Blades: 16
• Weight: 1600g

20-55mm:

• T-Stop: T2.8 – T22
• Optical Construction: 18 elements in 15 groups
• Close Focus: 0,6m
• Iris Control: 65°
• Focus Control: 270°
• Zoom Control: 100°
• Iris Blades: 16
• Weight: 1520g

50-125mm:

• Optical Construction: 18 elements in 13 groups
• Close Focus: 0,8m
• Iris Control: 72°
• Focus Control: 270°
• Zoom Control: 100°
• Iris Blades: 16
• Weight: 1700g
