ZILR SDI 12G BNC Cable 2m
ZILR 12G SDI Cable supports signals from 12G-SDI, 6G-SDI, HD-SDI and 3G-SDI.
Designed for use for professional equipment requiring an SDI connection.
This cable supports resolutions up to 4K.
- 4K @ 60Hz for resolutions up to 4096x2160
- Full HD 1080p
- BNC to BNC
- 2m / 6.6ft cable length
- Up to 12Gbit/s bitrates
- Supports 12G/6G/3G/HD/SD
- Cable thinkness of 3.0+/-0.15mm
- Shielding: Copper Braid >85%
- Wire Gauge: 28AWG
- Coaxial Type: RG-6
- Insulation Type: Polyethylene 80p
- Connectors: Gold Pin Connection 15u"
- VSWR (Voltage Standing Wave Ratio): 1.5D-2V
- Frequency: DC to 12 GHz
- Maximum Impedance: >75 Ohms
