ZILR SDI 12G BNC CABLE 45CM

ZILR SDI 12G BNC Cable 45cm

ZILR 12G SDI Cable supports signals from 12G-SDI, 6G-SDI, HD-SDI and 3G-SDI.
Designed for use for professional equipment requiring an SDI connection.
This cable supports resolutions up to 4K.

Features:

• 4K @ 60Hz for resolutions up to 4096x2160
• Full HD 1080p
• BNC to BNC
• 2m / 6.6ft cable length
• Up to 12Gbit/s bitrates
• Supports 12G/6G/3G/HD/SD
• Cable thinkness of 3.0+/-0.15mm
• Shielding: Copper Braid >85%
• Wire Gauge: 28AWG
• Coaxial Type: RG-6
• Insulation Type: Polyethylene 80p
• Connectors: Gold Pin Connection 15u"
• VSWR (Voltage Standing Wave Ratio): 1.5D-2V
• Frequency: DC to 12 GHz
• Maximum Impedance: >75 Ohms
